Specifications

• Input: AC 100 - 240V 50-60HZ
• Output: DC 14.6V 10A (10000mAh)
• Connector Type: Alligator Clamps
• Dimensions (LxWxH): 118mm(4.6") x 64mm(2.5") x 40mm(1.6")
• Weight: 11.2 oz (320 g)

Features

• Smart charger designed to charge 12.8v LiFePO4 battery pack with capacity >= 10000 mAh
• CCCV charging mode, and power off when battery voltage reaches 14.6V
• Led 1 - Red = Power on. LED 2 - Red = Charging. LED 2 - Green = Fully Charged.
• Short Circuit / Over-voltage / Output-reversed Protection
• Built in cooling fan to ensure charger long service life
• Charge time = (Ah rate of the pack x 1.41) / 10A charge current
